Heat Pipe Thermal Moudle Parts

Our Heat Pipe Thermal Module Parts are high-performance Heat Pipe Assemblies designed for efficient high-power cooling in demanding applications. Built based on public mold heat sink specifications, these modules provide superior thermal management for high-power LED, IGBT modules, and TEC modules (customizable). Available in multiple standard specifications with customizable dimensions, these Heat Sink With Heat Pipe solutions combine precision-engineered aluminum bases with integrated copper heat pipes and optimized fin structures, ensuring high thermal conductivity, excellent reliability, and cost-effective solutions for mass production. Our modules are ideal for engineers looking for a Heat Sink solution that balances performance, compatibility, and flexibility, while maintaining industrial-grade durability.

Key Features

• Multiple Specifications for High-Power Cooling – Perfect for high-power LED systems, IGBT modules, and TEC modules.

• Integrated Heat Pipe Technology – Embedded copper heat pipes allow rapid heat transfer, reducing hotspot formation.

• Optimized Fin Structure – Skived or bonded fins provide large surface area and improve airflow efficiency.

• Public Mold Reference Design – Ensures compatibility with standard module layouts for quick installation.

• Customizable Size and Shape – Length, width, height, and fin arrangement can be tailored to your system’s thermal requirements.

• Surface Treatment Options – Black anodized, clear anodized, or powder coating for improved corrosion resistance and durability.

• Mass Production Ready – Designed for rapid deployment without compromising performance.

Applications

Applicable to High-Power LED / IGBT Module / TEC Module (Customizable)

• High-power LED lighting systems – streetlights, stadiums, industrial high-bay lighting

• IGBT power modules and inverters – solar inverters, wind turbine converters, motor drives

• TEC (Thermoelectric Cooler) modules – lasers, medical devices, precision cooling systems

• Industrial power supplies and communication equipment – servers, data centers, and 5G infrastructure

• Renewable energy and EV systems – battery storage, EV chargers, and other high-power electronics

Customization Options

In addition to standard public mold heat sink models, we provide:

• Custom Dimensions – Fully tailored to PCB layout, enclosure, or module footprint

• Heat Pipe Quantity and Layout – Optimized for uniform heat spreading

• Fin Density & Arrangement – Adjustable for forced convection efficiency

• Surface Finish Options – Anodized or powder-coated for corrosion resistance and aesthetics

• Mounting & Integration Features – Custom screw holes, clips, and brackets for easy installation

These Heat Pipe Thermal Module Parts allow engineers to implement high-performance thermal management solutions efficiently and reliably.

Technical Advantages

• High Thermal Performance – Optimized heat pipe layout and fin design for low thermal resistance (°C/W)

• Reliable Mechanical Strength – Resistant to vibration, shocks, and thermal cycling

• Wide Compatibility – Supports public mold reference designs for seamless integration

• Rapid Deployment – Standard models ready for quick sampling and mass production

• Flexible Customization – Size, fin structure, surface treatment, and heat pipe layout tailored to project requirements

Why Choose Our Heat Pipe Thermal Module Parts?

1. Proven Public Mold Reference Design – Ensures compatibility and faster integration.

2. High-Performance Thermal Management – Optimized Heat Pipe Assemblies for large heat sink applications.

3. Customizable Solutions – Tailored size, heat pipe layout, and surface treatments for any project.

4. Mass Production & Reliability – Consistent quality for industrial and commercial applications.

5. Technical Support from Experienced Heat Sink Manufacturer – Guidance for integrating Heat Sink With Heat Pipe and Heat Pipe Thermal Module solutions into your design.

Our Heat Pipe Thermal Module Parts provide a reliable, efficient, and customizable Heat Sink solution, making them ideal for engineers designing high-power cooling systems for LEDs, IGBT modules, and TEC modules.

For more details on specifications, sizes, and customization options, please download our product catalog of Heat Pipe Thermal Module Parts.
